KMT1

Ondrives Precision Gears and Gearboxes Part number KMT1

KMT1

High Precision Bearing Locknut, M12
Ondrives Precision Gears and Gearboxes Part number KMT1 Ondrives Precision Gears and Gearboxes Part number KMT1 Ondrives Precision Gears and Gearboxes Part number KMT1

Product specifications

Thread [M x P]M12 x 1
Diameter [D]30
Diameter [D1]25
Diameter [D2]13
Diameter [D3]23
Dimension [k] [H]14
Dimension [S]4
Dimension [T]2
Dimension [W]27
Static Axial Load Carrying Capacity [kN]40
Mass [kg]0.05
GrubscrewM5
Recommended Grubscrew Tightening Torque [Nm]4.5

Product specifications

Thread [M x P]M12 x 1
Diameter [D]30
Diameter [D1]25
Diameter [D2]13
Diameter [D3]23
Dimension [k] [H]14
Dimension [S]4
Dimension [T]2
Dimension [W]27
Static Axial Load Carrying Capacity [kN]40
Mass [kg]0.05
GrubscrewM5
Recommended Grubscrew Tightening Torque [Nm]4.5
