KMT14

Ondrives Precision Gears and Gearboxes Part number KMT14

KMT14

High Precision Bearing Locknut, M70
Ondrives Precision Gears and Gearboxes Part number KMT14 Ondrives Precision Gears and Gearboxes Part number KMT14 Ondrives Precision Gears and Gearboxes Part number KMT14

Product specifications

Thread [M x P]M70 x 2
Diameter [D]100
Diameter [D1]92
Diameter [D2]72
Diameter [D3]88
Dimension [k] [H]28
Dimension [S]8
Dimension [T]3.5
Dimension [W]95
Static Axial Load Carrying Capacity [kN]490
Mass [kg]0.75
GrubscrewM8
Recommended Grubscrew Tightening Torque [Nm]18

Product specifications

Thread [M x P]M70 x 2
Diameter [D]100
Diameter [D1]92
Diameter [D2]72
Diameter [D3]88
Dimension [k] [H]28
Dimension [S]8
Dimension [T]3.5
Dimension [W]95
Static Axial Load Carrying Capacity [kN]490
Mass [kg]0.75
GrubscrewM8
Recommended Grubscrew Tightening Torque [Nm]18
