KMT2

Ondrives Precision Gears and Gearboxes Part number KMT2

KMT2

High Precision Bearing Locknut, M15
Ondrives Precision Gears and Gearboxes Part number KMT2 Ondrives Precision Gears and Gearboxes Part number KMT2 Ondrives Precision Gears and Gearboxes Part number KMT2

Product specifications

Thread [M x P]M15 x 1
Diameter [D]33
Diameter [D1]28
Diameter [D2]16
Diameter [D3]26
Dimension [k] [H]16
Dimension [S]4
Dimension [T]2
Dimension [W]30
Static Axial Load Carrying Capacity [kN]60
Mass [kg]0.075
GrubscrewM5
Recommended Grubscrew Tightening Torque [Nm]4.5

Product specifications

Thread [M x P]M15 x 1
Diameter [D]33
Diameter [D1]28
Diameter [D2]16
Diameter [D3]26
Dimension [k] [H]16
Dimension [S]4
Dimension [T]2
Dimension [W]30
Static Axial Load Carrying Capacity [kN]60
Mass [kg]0.075
GrubscrewM5
Recommended Grubscrew Tightening Torque [Nm]4.5
