KMT5

Ondrives Precision Gears and Gearboxes Part number KMT5

KMT5

High Precision Bearing Locknut, M25
Ondrives Precision Gears and Gearboxes Part number KMT5 Ondrives Precision Gears and Gearboxes Part number KMT5 Ondrives Precision Gears and Gearboxes Part number KMT5

Product specifications

Thread [M x P]M25 x 1.5
Diameter [D]44
Diameter [D1]39
Diameter [D2]26
Diameter [D3]36
Dimension [k] [H]20
Dimension [S]5
Dimension [T]2
Dimension [W]41
Static Axial Load Carrying Capacity [kN]130
Mass [kg]0.13
GrubscrewM6
Recommended Grubscrew Tightening Torque [Nm]8

Product specifications

Thread [M x P]M25 x 1.5
Diameter [D]44
Diameter [D1]39
Diameter [D2]26
Diameter [D3]36
Dimension [k] [H]20
Dimension [S]5
Dimension [T]2
Dimension [W]41
Static Axial Load Carrying Capacity [kN]130
Mass [kg]0.13
GrubscrewM6
Recommended Grubscrew Tightening Torque [Nm]8
