KMT7

Ondrives Precision Gears and Gearboxes Part number KMT7

KMT7

High Precision Bearing Locknut, M35
Ondrives Precision Gears and Gearboxes Part number KMT7 Ondrives Precision Gears and Gearboxes Part number KMT7 Ondrives Precision Gears and Gearboxes Part number KMT7

Product specifications

Thread [M x P]M35 x 1.5
Diameter [D]54
Diameter [D1]49
Diameter [D2]38
Diameter [D3]46
Dimension [k] [H]22
Dimension [S]5
Dimension [T]2
Dimension [W]50
Static Axial Load Carrying Capacity [kN]190
Mass [kg]0.19
GrubscrewM6
Recommended Grubscrew Tightening Torque [Nm]8

Product specifications

Thread [M x P]M35 x 1.5
Diameter [D]54
Diameter [D1]49
Diameter [D2]38
Diameter [D3]46
Dimension [k] [H]22
Dimension [S]5
Dimension [T]2
Dimension [W]50
Static Axial Load Carrying Capacity [kN]190
Mass [kg]0.19
GrubscrewM6
Recommended Grubscrew Tightening Torque [Nm]8
