KMT9

Ondrives Precision Gears and Gearboxes Part number KMT9

KMT9

High Precision Bearing Locknut, M45
Ondrives Precision Gears and Gearboxes Part number KMT9 Ondrives Precision Gears and Gearboxes Part number KMT9 Ondrives Precision Gears and Gearboxes Part number KMT9

Product specifications

Thread [M x P]M45 x 1.5
Diameter [D]70
Diameter [D1]64
Diameter [D2]48
Diameter [D3]60
Dimension [k] [H]22
Dimension [S]6
Dimension [T]2.5
Dimension [W]65
Static Axial Load Carrying Capacity [kN]240
Mass [kg]0.33
GrubscrewM8
Recommended Grubscrew Tightening Torque [Nm]18

Product specifications

Thread [M x P]M45 x 1.5
Diameter [D]70
Diameter [D1]64
Diameter [D2]48
Diameter [D3]60
Dimension [k] [H]22
Dimension [S]6
Dimension [T]2.5
Dimension [W]65
Static Axial Load Carrying Capacity [kN]240
Mass [kg]0.33
GrubscrewM8
Recommended Grubscrew Tightening Torque [Nm]18
