OKBS70-48X80

bellow coupling servo Precision from Ondrives UK precision gear and gearbox manufacturer

OKBS70-48X80

C60 Steel Internal Locking Assemblies, Self Centering, High Concentricity and Rectangularity
bellow coupling servo Precision from Ondrives UK precision gear and gearbox manufacturer bellow coupling servo Precision from Ondrives UK precision gear and gearbox manufacturer

Product specifications

Diameter [B]48
Diameter [D]80
Torque (Nm)2510
Dimension [L]55
Dimension [L1]30
Dimension [b]36
Dimension [L3]47
Shaft Pw N/mm²218
Hub Pn (N/mm²)135
No. of Screws6
Cap Screw Din 912M8x30
Ta (Nm)41
Mass [kg]0.95

Product specifications

Diameter [B]48
Diameter [D]80
Torque (Nm)2510
Dimension [L]55
Dimension [L1]30
Dimension [b]36
Dimension [L3]47
Shaft Pw N/mm²218
Hub Pn (N/mm²)135
No. of Screws6
Cap Screw Din 912M8x30
Ta (Nm)41
Mass [kg]0.95
