PFN40NM 18Nm NEMA 23 IP66 37.5mm-Centres
Precision Worm Wheel Reducers
Manufactured by Ondrives in the UK
| Sku (Part No.) | Gear Ratio [i=] | Output Torque T₂n [Nm] | Output Backlash j |
|---|---|---|---|
| PFN40-10NM | 10:1 | 7.10 | ≤0.16° |
| PFN40-12NM | 12:1 | 7.50 | ≤0.16° |
| PFN40-15NM | 15:1 | 8.00 | ≤0.16° |
| PFN40-20NM | 20:1 | 8.20 | ≤0.16° |
| PFN40-30NM | 30:1 | 9.00 | ≤0.16° |
| PFN40-60NM | 60:1 | 10.00 | ≤0.16° |
| PFN40-120NM | 120:1 | 8.70 | ≤0.16° |
| PFN40-10ANM | 10:1 | 7.10 | ≤0.08° |
| PFN40-12ANM | 12:1 | 7.50 | ≤0.08° |
| PFN40-15ANM | 15:1 | 8.00 | ≤0.08° |
| PFN40-20ANM | 20:1 | 8.20 | ≤0.08° |
| PFN40-30ANM | 30:1 | 9.00 | ≤0.08° |
| PFN40-60ANM | 60:1 | 10.00 | ≤0.08° |
| PFN40-120ANM | 120:1 | 8.70 | ≤0.08° |
