| Gear Ratio [i=] | 1:1 |
| Output Torque T₂max [Nm] | 350 |
| Nom Output Torque T₂n [Nm] | 250 |
| Nom. Input Speed S5 T₂n [n1nom] | 1000 min-1 (r/min) |
| Max. Input Speed [n1max] | 3500 min-1 (r/min) |
| Output Backlash j | ≤0.1° |
| Efficiency n1nom [ηz] | ≈98% |
| Reflected Inertia at Input (kg•m²) | 2.02x10-3 |
| Mass [kg] | 15.188 |
| Max. Input Radial Load Fr1 N | 3000 |
| Max. Output Radial Load Fr2 N | 3000 |
| Max. Input Axial Load Fa1 N | 1750 |
| Max. Output Axial Load Fa2 N | 1750 |
| Lubrication Oil | Klubersynth GH 6-220 |
| Max. Operating Temp of Lub | ≈95°C |
| Thermal Rating S1 Pthermal [kw] | 9 |
| Seals | Fluoro-Elastomer FPM ISO 1629 /FKM ASTM D141 H |
| Ingress Protection | IP64 |
| Noise Level Low Load | ≈75dB(A) |
