Gear Ratio [i=] | 1:1 |
Output Torque T₂max [Nm] | 70 |
Nom Output Torque T₂n [Nm] | 35 |
Nom. Input Speed S5 T₂n [n1nom] | 1500 min-1 (r/min) |
Max. Input Speed [n1max] | 5500 min-1 (r/min) |
Output Backlash j | ≤0.1° |
Efficiency n1nom [ηz] | ≈98% |
Reflected Inertia at Input (kg•m²) | 6.66 x 10-5 |
Mass [kg] | 2.3 |
Max. Input Radial Load Fr1 N | 500 |
Max. Output Radial Load Fr2 N | 500 |
Max. Input Axial Load Fa1 N | 200 |
Max. Output Axial Load Fa2 N | 200 |
Lubrication Oil | Klubersynth GH 6-220 |
Max. Operating Temp of Lub | ≈95°C |
Thermal Rating S1 Pthermal [kw] | 3 |
Seals | Fluoro-Elastomer FPM ISO 1629 /FKM ASTM D141 H |
Ingress Protection | IP64 |
Noise Level Low Load | ≈75dB(A) |
