692XZZ

Ondrives Precision Gears and Gearboxes Part number 692XZZ

692XZZ

Steel Miniature Ball Bearing. Metal Shielded Type ZZ. 2.5mm Bore
Ondrives Precision Gears and Gearboxes Part number 692XZZ Ondrives Precision Gears and Gearboxes Part number 692XZZ

Product specifications

Bore Diameter [d]2.5
Diameter [A]7
Dimension [B]3.5
Dimension [r] Min.0.15
Static Load Rating [N]118
Dynamic Load Rating [N]363
Max. Speed [rpm]63000

Product specifications

Bore Diameter [d]2.5
Diameter [A]7
Dimension [B]3.5
Dimension [r] Min.0.15
Static Load Rating [N]118
Dynamic Load Rating [N]363
Max. Speed [rpm]63000
