    Crossed Axis Helical Gearboxes

    Ondrives crossed axis helical gearboxes offer an excellent solution where a 90 degree drive is required.
    Crossed Helical Rotation Direction.
    Using different helix direction changes direction of rotation compared to input compared to the other helix direction.
    Helix Direction RH-Right Hand - When input rotation is clockwise , output is pulled towards input. When input is counter-clockwise , output is pushed away from input.

    Helix Direction LH-Left Hand    - When input rotation is clockwise , output is pushed away from input. When input is counter-clockwise , output is pulled towards input.
    See more on our gear reducers and gearboxes at:

    Ondrives Gearboxes Gear Reducer Info Page

    View as Grid List
    Sort by
    Display per page
    Low Backlash Right angle crossed axis helical gearbox reducer bore input and output compact design made by Ondrives Precision Gears and Gearboxes

    E15-10A

    E15-10A
    Right angle crossed axis helical gearbox reducer, ≤30' backlash, 6mm shafts, 0.79Nm-2.44Nm output torque, ratio 10:1
    Right angle crossed axis helical gearbox reducer bore input and output compact design made by Ondrives Precision Gears and Gearboxes

    E15-1

    E15-1
    Right angle crossed axis helical gearbox reducer, ≤45'° backlash, 6mm shafts, 0.40Nm-1.32Nm output torque, ratio 1:1
    Right angle crossed axis helical gearbox reducer bore input and output compact design made by Ondrives Precision Gears and Gearboxes

    E15-10

    E15-10
    Right angle crossed axis helical gearbox reducer, ≤45' backlash, 6mm shafts, 0.79Nm-2.44Nm output torque, ratio 10:1
    Low Backlash Right angle crossed axis helical gearbox reducer bore input and output compact design made by Ondrives Precision Gears and Gearboxes

    E15-10A-LH

    E15-10A-LH
    Right angle crossed axis helical gearbox reducer, ≤30' backlash, 6mm shafts, 0.79Nm-2.44Nm output torque, ratio 10:1
    Low Backlash Right angle crossed axis helical gearbox reducer bore input and output compact design made by Ondrives Precision Gears and Gearboxes

    E15-10AR

    E15-10AR
    Right angle crossed axis helical gearbox reducer, ≤10' backlash, 6mm shafts, 0.79Nm-2.44Nm output torque, ratio 10:1
    Low Backlash Right angle crossed axis helical gearbox reducer bore input and output compact design made by Ondrives Precision Gears and Gearboxes

    E15-10AR-LH

    E15-10AR-LH
    Right angle crossed axis helical gearbox reducer, ≤10' backlash, 6mm shafts, 0.79Nm-2.44Nm output torque, ratio 10:1
